Output Type:
4-20 mA, Relay
Supply Voltage:
100 → 240 V ac
Size:
95.8 x 95.8mm
Number of Inputs:
2
Number of Outputs:
2
Minimum Operating Temperature:
0°C
Maximum Operating Temperature:
+50°C
Temperature Range:
0 → +600 (E Type) °C, 0 → +1700 (R Type) °C, 0 → +1700 (S Type) °C, -100 → +1200 (J Type) °C, -148 → +2192 (J Type) °F, -200 → +400 (T Type) °C, -200 → +500 (U Type) °C, -200 → +800 (TXK Type) °C, -200 → +850 (L Type) °C, -200 → +1300 (K Type) °C, -200 → +1300 (N Type) °C, -328 → +752 (T Type) °F, -328 → +932 (U Type)°F, -328 → +1472 (TXK Type) °F, -328 → +1562 (L Type) °F, -328 → +2372 (K Type) °F, -328 → +2372 (N Type) °F, +32 → +1112 (E Type) °F, +32 → +3092 (R Type) °F, +32 → +3092 (S Type) °F, +100 → +1800 (B Type) °C, +212 → +3272 (B Type) °F
Control Type:
PID Controller
Communication Module Available:
Yes
Display Type:
LCD
IP Rating:
IP65
Series:
PXU
Input Type:
Analogue
Mounting Type:
Panel Mount
Panel Depth:
72mm
Termination Type:
Screw
