Maximum Load Current:
50 A rms
Mounting Type:
Panel Mount
Maximum Load Voltage:
280 V ac
Minimum Load Voltage:
24 V ac
Maximum Control Voltage:
32 V dc
Minimum Control Voltage:
3 V dc
Switching Type:
Zero Cross
Control Voltage Range:
3 → 32 V dc
Minimum Load Current:
100mA rms
Range:
Easy Pick
Number of Poles:
1
Terminal Type:
Screw
Output Device:
SCR
Relay Type:
Solid State Relay
Maximum Turn On Time:
1/2 cycle
Series:
8413
Load Voltage Range:
24 → 280V ac
Dimensions:
44.5 x 57.3 x 30.9mm
Operating Temperature Range:
-40 → +80°C
Special Features:
Improved SEMS Screw & Washer, IP20, LED Input Status Indicator, Redesigned Housing with Anti-Rotation Barriers
Length:
44.5mm
Off State Leakage Current:
0.1mA rms
Maximum Operating Temperature:
+80°C
Standards Met:
CE, CSA LR 38595, cULus Recognised E79183, EMC Compliant, EN 60950-1, EN 62314:2006, IEC, IEC 61000-4-2, IEC 61000-4-4, TUV, UL
Depth:
57.3mm
Height:
30.9mm
Capacitance:
8pF
Minimum Operating Temperature:
-40°C
