Maximum DC Voltage:
110V
Maximum AC Voltage:
250V
Better World Product:
Yes
Illuminated:
Yes
Mounting Type:
Panel Mount
IP Rating:
IP65
Series:
Harmony XB6E
Minimum Operating Temperature:
-25°C
Better World Verification:
Green Premium
Push Button Style:
Rectangular
Contact Configuration:
DPDT
Push Button Colour:
Red
Panel Cut Out Diameter:
16mm
Manufacturer Part No.:
XB6EDW4B2P
Maximum Operating Temperature:
+55°C
Terminal Type:
Quick Connect, Solder Tag
HTSUS:
8536.50.9033
RoHS Status:
ROHS3 Compliant
Electrical Life:
100,000 Cycles
Termination Style:
Quick Connect - 0.110" (2.8mm)
Voltage Rating - DC:
24 V
Operating Temperature:
-10°C ~ 55°C
Panel Cutout Dimensions:
Circular - 16.00mm Dia
Mechanical Life:
1,000,000 Cycles
Type:
Standard, Illuminated
Color - Actuator/Cap:
Red
title:
XB6EDW4B2P
Voltage Rating - AC:
120 V
Illumination Type, Color:
LED, Red
Switch Function:
Off-On
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Circuit:
DPST-NC
Current Rating (Amps):
1.5A (AC), 1A (DC)
Ingress Protection:
IP65 - Dust Tight, Water Resistant
Features:
-
Mounting Type:
Panel Mount, Front
Series:
Harmony XB6E
Packaging:
Box
Actuator Type:
Rectangular, Button, Flush
Illumination Voltage (Nominal):
24 VDC
ECCN:
EAR99
