Thread Size:
M18
Sensor Technology:
Ultrasonic
Detection Range:
1.2 m
Body Style:
Block
Output Function:
NO/NC
Digital Switching Output Type:
PNP
Connection Type:
M12
Supply Voltage:
10 → 30 V dc
Length:
53mm
IP Rating:
IP67
Width:
20mm
Housing Material:
Epoxy Glass Ceramic, PBT, Polyamide, Stainless Steel
Maximum DC Voltage:
30V
Minimum Operating Temperature:
-20°C
Maximum Switching Frequency:
48.4V
Reverse Polarity Protection:
Yes
Depth:
37.7mm
Short Circuit Overload Protection:
Yes
Switching Current:
35 mA
Switching Frequency:
5.9 (Dia.) x 8.7mm
Maximum Operating Temperature:
+70°C
Standards Met:
CE, cULus, cULus Recognised, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, UL
