Thread Size:
M18
Sensor Technology:
Ultrasonic
Body Style:
Threaded Barrel
Detection Range:
800 mm
Digital Switching Output Type:
PNP
Output Function:
NO/NC
Connection Type:
M12
Supply Voltage:
10 → 30 V dc
Length:
60.5mm
IP Rating:
IP67
Housing Material:
Epoxy Glass Ceramic, Polyamide, Stainless Steel
Maximum DC Voltage:
30V
Minimum Operating Temperature:
-20°C
Short Circuit Overload Protection:
Yes
Switching Current:
35 mA
Maximum Switching Frequency:
48.4V
Reverse Polarity Protection:
Yes
Maximum Operating Temperature:
+70°C
Standards Met:
CE, cULus, cULus Recognised, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, UL
Switching Frequency:
5.9 (Dia.) x 8.7mm
