Thread Size:
M18
Sensor Technology:
Ultrasonic
Body Style:
Block
Detection Range:
300 mm
Output Function:
NO/NC
Digital Switching Output Type:
PNP
Connection Type:
M12
Supply Voltage:
10 → 30 V dc
IP Rating:
IP67
Length:
53mm
Housing Material:
Epoxy Glass Ceramic, PBT, Polyamide, Stainless Steel
Width:
20mm
Maximum DC Voltage:
30V
Minimum Operating Temperature:
-20°C
Maximum Operating Temperature:
+70°C
Switching Frequency:
8 Hz
Switching Current:
35 mA
Maximum Switching Frequency:
8Hz
Short Circuit Overload Protection:
Yes
Standards Met:
CE, cULus, cULus Recognised, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, UL
Depth:
37.7mm
Reverse Polarity Protection:
Yes
