Thread Size:
M18
Sensor Technology:
Ultrasonic
Body Style:
Threaded Barrel
Detection Range:
300 mm
Digital Switching Output Type:
PNP
Output Function:
NO/NC
Connection Type:
M12
Supply Voltage:
10 → 30 V dc
IP Rating:
IP67
Length:
60.5mm
Housing Material:
Epoxy Glass Ceramic, PBT, Polyamide
Maximum DC Voltage:
30V
Minimum Operating Temperature:
-20°C
Maximum Switching Frequency:
8Hz
Short Circuit Overload Protection:
Yes
Switching Current:
35 mA
Reverse Polarity Protection:
Yes
Standards Met:
CE, cULus, cULus Recognised, EN 55011, EN 60068-2-27, EN 60068-2-6, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-6, UL
Maximum Operating Temperature:
+70°C
Switching Frequency:
8 Hz
