Pressure Reading Type:
Differential
Minimum Pressure Reading:
20 (Falling) bar, 32 (Rising) bar
Maximum Pressure Reading:
388 (Falling) bar, 400 (Rising) bar
Accuracy:
≤0.2 (Repeat) %, ≤0.6 (Output) %, ≤1 (Overall) %
Output Type:
Analogue, PNP-NO/NC
Media Measured:
Air, Fresh Water, Hydraulic Oil, Refrigeration Fluid
Process Connection:
G1/4
Analogue Output:
4 → 20 mA
Electrical Connection:
M12 4-Pin Connector
Response Time:
≤10 (Analogue) ms, ≤5 (Discrete) ms
Maximum Current:
≤50 mA
Supply Voltage:
24 V dc
Housing Material:
Polyacrylamide, Stainless Steel 316L
IP Rating:
IP65, IP67
Minimum Operating Temperature:
-20°C
Mounting Type:
Vertical Mount
Maximum Operating Temperature:
+80°C
