Coil Voltage:
12V dc
Contact Configuration:
SPST
Mounting Type:
PCB Mount
Switching Current:
10A
Number of Poles:
1
Latching:
No
Terminal Type:
PCB Pin
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
30V dc
Length:
20mm
Coil Resistance:
720Ω
Coil Power:
200mW
Depth:
10mm
Minimum Operating Temperature:
-40°C
Height:
15.6mm
Contact Material:
Silver Alloy
Maximum Operating Temperature:
+85°C
Isolation Coil To Contact:
4kVrms
Standards Met:
CQC, CSA, cUL, cULus, UL, VDE
Life:
Minimum of 10000000 (Mechanical) operations
Maximum Switching Power AC:
1.25 kVA
Maximum Switching Power DC:
150 W
Application:
Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine
