Coil Voltage:
24V dc
Contact Configuration:
DPST, SPST
Mounting Type:
PCB Mount
Switching Current:
35A
Number of Poles:
3
Latching:
No
Terminal Type:
PCB Pin
Maximum Switching Voltage AC:
277 (Form B) V, 480 (Form A) V
Maximum Switching Voltage DC:
110V dc
Length:
30mm
Coil Resistance:
306.4Ω
Coil Power:
1.88W
Height:
40mm
Minimum Operating Temperature:
-40°C
Life:
Minimum of 100000 (Form B-Electrical) operations, Minimum of 30000 (Form A-Electrical) operations, Minimum of 5000000 (Mechanical) operations
Standards Met:
cUL, cULus, UL, VDE
Depth:
36mm
Contact Material:
Silver Alloy
Isolation Coil To Contact:
2000 (Form A) Vrms, 2000 (Form B) Vrms
Maximum Operating Temperature:
+85°C
Maximum Switching Power AC:
277 (Form B) VA, 9695 (Form A) VA
Application:
Industrial Equipment, Inverter, Office Air Conditioner, Photovoltaic Power Generation Systems, Uninterruptible Power Supplies
