Coil Voltage:
48V ac
Contact Configuration:
DPST-C/O
Mounting Type:
Plug In
Number of Poles:
2
Latching:
No
Terminal Type:
Plug In
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
30V dc
Length:
13mm
Coil Resistance:
1100Ω
Coil Power:
820mW
Isolation Coil To Contact:
5kV ac
Better World Product:
Yes
Height:
30.6mm
Maximum Operating Temperature:
+70°C
Series:
Harmony Relay RXG
Minimum Operating Temperature:
-40°C
Standards Met:
CE, CSA, CULus, cURus File E173076 CCN NRNT2, IEC/EN 61810-1, NRNT7, NRNT8, UL
Contact Material:
Silver Alloy
Life:
10000000 cycles
Depth:
37.1mm
Better World Verification:
Green Premium
Maximum Switching Power AC:
1.25 kVA
Maximum Switching Power DC:
150 W
Application:
Industrial
