Coil Voltage:
5V dc
Contact Configuration:
SPST
Mounting Type:
PCB Mount
Switching Current:
16A
Number of Poles:
1
Latching:
Yes
Terminal Type:
PCB Pin
Maximum Switching Voltage AC:
277V
Length:
24mm
Coil Resistance:
62.5Ω
Coil Power:
400mW
Height:
15.8mm
Standards Met:
CSA, cUL, cULus, PTI 325V, TV-8, UL, VDE
Contact Material:
Silver Alloy
Depth:
10mm
Life:
Minimum of 1000000 (Mechanical) operations, Minimum of 20000 (Electrical) operations
Maximum Operating Temperature:
+70°C
Isolation Coil To Contact:
5kVrms
Minimum Operating Temperature:
-40°C
Maximum Switching Power AC:
4.432 kVA
Dimensions:
24 x 10 x 15.8mm
Application:
Home Appliances, Industrial Equipment, Lighting Control Equipment, Security Equipment, Smart Meters, Various Power Supplies
