Coil Voltage:
24V dc
Contact Configuration:
SPDT
Mounting Type:
PCB Mount
Number of Poles:
1
Latching:
No
Terminal Type:
PCB Pin
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
30V dc
Length:
20mm
Coil Resistance:
1440Ω
Coil Power:
400mW
Maximum Operating Temperature:
+85°C
Contact Material:
Silver Alloy
Depth:
10mm
Minimum Operating Temperature:
-40°C
Isolation Coil To Contact:
4kVrms
Standards Met:
CQC, CSA, cUL, cULus, UL, VDE
Height:
15.6mm
Life:
Minimum of 10000000 (Mechanical) operations
Maximum Switching Power AC:
1250 (NO) VA, 500 (NC) VA
Maximum Switching Power DC:
150 (NO) W, 30 (NC) W
Dimensions:
20 x 10 x 15.6mm
Application:
Air Conditioners, Cooking Ovens, Home Appliances, Industrial Equipment, Motor Controls, Power Supply, Refrigerators, Robots, Washing Machine
