Multimeter Type:
Handheld
Model Number p:
87V
Display Type:
Digital
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+1090°C
Absolute Maximum Capacitance Measurement:
9.999F
Maximum Frequency:
20kHz
DC Current Measurement Resolution:
0.1µA dc
AC Current Measurement Resolution:
0.1µA ac
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
AC Voltage Measurement Resolution:
0.1mV ac
Capacitance Measurement Resolution:
10nF
Temperature Measurement Resolution:
0.1°C
Safety Category Level:
CAT III, CAT IV
Height:
31mm
Minimum Operating Temperature:
-20°C
Best DC Current Accuracy:
±0.2% + 2 Digits
Best DC Voltage Accuracy:
±0.05% + 1 Digit
Length:
186mm
Best Resistance Measurement Accuracy:
±1% + 3 Digits
Battery Type:
9V
Safety Category Voltage:
664 V, 1000V
Best Capacitance Measurement Accuracy:
±1% + 2 Digits
Best AC Voltage Accuracy:
±2% + 4 Digits
Maximum Operating Temperature:
+55°C
Weight:
355g
Best AC Current Accuracy:
±1% + 2 Digits
Width:
86mm
Best Temperature Measurement Accuracy:
±1% + 1 °C
Dimensions:
186 x 86 x 31mm
