Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
DM93-2
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity Threshold, DC Current, DC Voltage, Diode Test, Frequency, Resistance, Temperature, VFD AC Voltage
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum DC Voltage Measurement:
1000V dc
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
40mF
Absolute Maximum Temperature Measurement:
+1200°C
Maximum Frequency:
100kHz
Safety Category Level:
CAT III, CAT IV
Weight:
601g
Best DC Current Accuracy:
± 0.2 %
Minimum Operating Temperature:
-10°C
Height:
60.7mm
Dimensions:
207.1 x 98.1 x 60.7mm
Best Temperature Measurement Accuracy:
± 1 %
Best DC Voltage Accuracy:
± 0.05 %
Best Resistance Measurement Accuracy:
± 0.2 %
Maximum Operating Temperature:
+50°C
Battery Type:
AAA
Safety Category Voltage:
600 V, 1000 V
Width:
98.1mm
Best AC Current Accuracy:
± 1 %
Length:
207.1mm
Best AC Voltage Accuracy:
± 0.5 %
Best Capacitance Measurement Accuracy:
± 0.9 %
