Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
115
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum Resistance Measurement:
40MΩ
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Capacitance Measurement:
9.999F
True RMS:
Yes
Maximum Frequency:
1kHz
DC Current Measurement Resolution:
0.001A dc
AC Current Measurement Resolution:
0.001A ac
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
AC Voltage Measurement Resolution:
0.1mV ac
Safety Category Level:
CAT III
Capacitance Measurement Resolution:
1nF
Application:
Electrical, Electronic
Width:
84mm
Safety Category Voltage:
600V
Best AC Current Accuracy:
±1.5% + 3 Digits
Best Capacitance Measurement Accuracy:
±1.9% + 2 Digits
Best AC Voltage Accuracy:
±1% + 3 Digits
Height:
2.5 to 5.5V
Minimum Operating Temperature:
-10°C
Weight:
550g
Best DC Current Accuracy:
±1% + 3 Digits
Best Resistance Measurement Accuracy:
±5% + 2 Digits
Battery Type:
9V
Dimensions:
46 x 84 x 167mm
Length:
46mm
Maximum Operating Temperature:
+50°C
Best DC Voltage Accuracy:
±0.5% + 2 Digits
