Multimeter Type:
Bench
Display Type:
Digital
Model Number p:
5491B
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum DC Current Measurement:
20A dc
Absolute Maximum AC Current Measurement:
20A ac
True RMS:
Yes
Maximum Frequency:
1MHz
AC Current Measurement Resolution:
1mA ac
DC Current Measurement Resolution:
1mA dc
AC Voltage Measurement Resolution:
1mV ac
Resistance Measurement Resolution:
1Ω
DC Voltage Measurement Resolution:
1mV dc
Safety Category Level:
CAT I, CAT II
Best AC Voltage Accuracy:
±3 %
Length:
225mm
Best AC Current Accuracy:
±2.5 %
Width:
335mm
Dimensions:
225 x 335 x 100mm
Best Resistance Measurement Accuracy:
±0.1 %
Height:
100mm
Weight:
2.5kg
Best DC Current Accuracy:
±0.25 %
Safety Category Voltage:
300 V, 1000V
Best DC Voltage Accuracy:
±0.02 %
