Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
87V
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
Calibrated:
RSCAL
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum DC Current Measurement:
10A dc
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
9.999F
Absolute Maximum Temperature Measurement:
+1090°C
Maximum Frequency:
20kHz
AC Current Measurement Resolution:
0.1µA ac
DC Current Measurement Resolution:
0.1µA dc
DC Voltage Measurement Resolution:
0.1mV dc
Resistance Measurement Resolution:
100mΩ
AC Voltage Measurement Resolution:
0.1mV ac
Temperature Measurement Resolution:
0.1°C
Capacitance Measurement Resolution:
10nF
Safety Category Level:
CAT III, CAT IV
Best Resistance Measurement Accuracy:
±1% + 3 Digits
Length:
186mm
Best DC Voltage Accuracy:
±0.05% + 1 Digit
Maximum Operating Temperature:
+55°C
Best AC Voltage Accuracy:
±2% + 4 Digits
Best Capacitance Measurement Accuracy:
±1% + 2 Digits
Minimum Operating Temperature:
-20°C
Best AC Current Accuracy:
±1% + 2 Digits
Width:
86mm
Dimensions:
186 x 86 x 31mm
Best Temperature Measurement Accuracy:
±1% + 1 °C
Height:
31mm
Weight:
355g
Best DC Current Accuracy:
±0.2% + 2 Digits
Safety Category Voltage:
664 V, 1000V
Battery Type:
9V
