Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
289
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Resistance, Temperature
Calibrated:
RSCAL
Absolute Maximum Resistance Measurement:
500MΩ
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Temperature Measurement:
+1350°C
Absolute Maximum Capacitance Measurement:
100mF
True RMS:
Yes
Maximum Frequency:
100kHz
AC Current Measurement Resolution:
0.01µA ac
DC Current Measurement Resolution:
0.01µA dc
DC Voltage Measurement Resolution:
1µV dc
Resistance Measurement Resolution:
10mΩ
AC Voltage Measurement Resolution:
1µV ac
Safety Category Level:
CAT III, CAT IV
Capacitance Measurement Resolution:
1pF
Temperature Measurement Resolution:
0.1°C
Best DC Voltage Accuracy:
±0.025% + 5 Digits
Length:
60mm
Maximum Operating Temperature:
+55°C
Best Temperature Measurement Accuracy:
±1% + 1 °C
Dimensions:
60 x 102 x 222mm
Best Capacitance Measurement Accuracy:
±1% + 5 Digits
Best AC Voltage Accuracy:
±0.4% + 40 Digits
Best AC Current Accuracy:
±0.7% + 5 Digits
Battery Type:
AA x 6
Safety Category Voltage:
600 V, 1000V
Width:
102mm
Best Resistance Measurement Accuracy:
±0.05% + 2 Digits
Minimum Operating Temperature:
-20°C
Height:
222mm
Weight:
870.9g
Best DC Current Accuracy:
±0.15% + 2 Digits
