Multimeter Type:
Handheld
Model Number p:
113
Display Type:
Digital
Calibrated:
RSCAL
Functions Measured:
AC Voltage, Capacitance, Continuity, DC Voltage, Diode, Resistance
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
60kΩ
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
9.999mF
Maximum Frequency:
1kHz
DC Voltage Measurement Resolution:
0.001V dc
Resistance Measurement Resolution:
100mΩ
AC Voltage Measurement Resolution:
0.001V ac
Safety Category Level:
CAT III, CAT IV
Capacitance Measurement Resolution:
1nF
Best Capacitance Measurement Accuracy:
±1.9% + 2 Digits
Best AC Voltage Accuracy:
±2% + 3 Digits
Width:
85.1mm
Dimensions:
46 x 85.1 x 167.1mm
Length:
46mm
Best DC Voltage Accuracy:
±2% + 3 Digits
Maximum Operating Temperature:
+50°C
Weight:
404g
Height:
167.1mm
Minimum Operating Temperature:
-10°C
Best Resistance Measurement Accuracy:
±0.9% + 1 Digit
Safety Category Voltage:
300 V, 600V
Battery Type:
9V
