Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
U1272A
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Resistance Measurement:
300MΩ
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum AC Voltage Measurement:
1000V ac
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
10mF
Absolute Maximum Temperature Measurement:
+1372°C
Moulded/Fold Flat:
Bluetooth
Maximum Frequency:
100kHz
DC Current Measurement Resolution:
0.01µA dc
AC Current Measurement Resolution:
0.01µA ac
DC Voltage Measurement Resolution:
0.001mV dc
Resistance Measurement Resolution:
1mΩ
AC Voltage Measurement Resolution:
0.01mV ac
Safety Category Level:
CAT III, CAT IV
Temperature Measurement Resolution:
0.1°C
Capacitance Measurement Resolution:
1pF
Best Temperature Measurement Accuracy:
±1% + 1 °C
Dimensions:
59 x 207 x 92mm
Best Capacitance Measurement Accuracy:
±1% + 2 Digits
Best AC Voltage Accuracy:
±0.6% + 20 Digits
Best AC Current Accuracy:
±0.6% + 25 Digits
Width:
207mm
Safety Category Voltage:
600 V, 1000V
Weight:
520g
Best DC Current Accuracy:
±0.2% + 5 Digits
Minimum Operating Temperature:
-20°C
Height:
92mm
Battery Type:
AAA x 4
Best Resistance Measurement Accuracy:
±0.2% + 5 Digits
Best DC Voltage Accuracy:
±0.05% + 2 Digits
Length:
59mm
Maximum Operating Temperature:
+55°C
