Multimeter Type:
Handheld
Model Number p:
27
Display Type:
Digital
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Diode, Frequency, Resistance
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Resistance Measurement:
50MΩ
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum Capacitance Measurement:
9.999F
True RMS:
Yes
Maximum Frequency:
20kHz
DC Current Measurement Resolution:
0.1µA dc
AC Current Measurement Resolution:
0.1µA ac
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
0.1mV dc
AC Voltage Measurement Resolution:
0.1mV ac
Safety Category Level:
CAT III, CAT IV
Capacitance Measurement Resolution:
10pF
Length:
198.1mm
Maximum Operating Temperature:
+55°C
Best Resistance Measurement Accuracy:
±0.05% + 1 Digit
Dimensions:
198.1 x 100 x 63.5mm
Best DC Voltage Accuracy:
±0.1% + 1 Digit
Battery Type:
AA x 3
Safety Category Voltage:
600 V, 1000V
Best DC Current Accuracy:
±0.2% + 2 Digits
Weight:
698.5g
Height:
63.5mm
Minimum Operating Temperature:
-15°C
Best Capacitance Measurement Accuracy:
±1% + 2 Digits
Best AC Voltage Accuracy:
±3% + 3 Digits
Width:
100mm
Best AC Current Accuracy:
±1.5% + 2 Digits
