Multimeter Type:
Bench
Model Number p:
1908P
Display Type:
Digital
Calibrated:
RSCAL
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Resistance Measurement:
1kΩ
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum Temperature Measurement:
+400°C
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
100µF
Maximum Frequency:
100kHz
DC Current Measurement Resolution:
100nA dc
AC Current Measurement Resolution:
100nA ac
AC Voltage Measurement Resolution:
1µV ac
Resistance Measurement Resolution:
1mΩ
DC Voltage Measurement Resolution:
1µV dc
Capacitance Measurement Resolution:
10pF
Temperature Measurement Resolution:
0.1°C
Safety Category Level:
CAT II
Best Capacitance Measurement Accuracy:
2 %
Best AC Voltage Accuracy:
0.3 %
Length:
260mm
Best AC Current Accuracy:
0.35 %
Width:
235mm
Maximum Operating Temperature:
+40°C
Battery Type:
Rechargeable NiMH
Safety Category Voltage:
600V
Dimensions:
260 x 235 x 88mm
Minimum Operating Temperature:
+5°C
Height:
88mm
Best Resistance Measurement Accuracy:
0.05 %
Weight:
2kg
Best DC Current Accuracy:
0.05 %
Best Temperature Measurement Accuracy:
0.05 %
Best DC Voltage Accuracy:
0.02 %
