Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
117
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
40MΩ
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
9.999F
Maximum Frequency:
Keyboard Switch
AC Current Measurement Resolution:
0.001A ac
DC Current Measurement Resolution:
0.001A dc
Resistance Measurement Resolution:
100mΩ
AC Voltage Measurement Resolution:
0.1mV ac
DC Voltage Measurement Resolution:
0.1mV dc
Application:
Electrical
Safety Category Level:
CAT III
Capacitance Measurement Resolution:
1nF
Best Capacitance Measurement Accuracy:
±1.9% + 2 Digits
Dimensions:
167 x 84 x 46mm
Best AC Voltage Accuracy:
±1% + 3 Digits
Weight:
550g
Height:
46mm
Minimum Operating Temperature:
-10°C
Best Resistance Measurement Accuracy:
±1.5% + 2 Digits
Battery Type:
9V
Safety Category Voltage:
600V
Maximum Operating Temperature:
+50°C
Length:
2.5 to 5.5V
Best DC Voltage Accuracy:
±0.5% + 2 Digits
Best DC Current Accuracy:
±1% + 3 Digits
Width:
84mm
Best AC Current Accuracy:
±1.5% + 3 Digits
