Multimeter Type:
Handheld
Model Number p:
3291
Display Type:
Digital
Calibrated:
RSCAL
Functions Measured:
AC Current, AC Voltage, Capacitance, Clamp Function, Continuity, DC Current, DC Voltage, DELTA REL, Diode, Frequency, MAX/MIN/AVG/PEAK, PWM Filter, Resistance, Temperature
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Current Measurement:
20A dc
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum AC Current Measurement:
20A ac
Absolute Maximum DC Voltage Measurement:
1000V dc
True RMS:
Yes
Absolute Maximum Capacitance Measurement:
60mF
Absolute Maximum Temperature Measurement:
+800°C
Maximum Frequency:
600kHz
AC Current Measurement Resolution:
0.01µA ac
DC Current Measurement Resolution:
0.01µA dc
AC Voltage Measurement Resolution:
0.001mV ac
DC Voltage Measurement Resolution:
0.001mV dc
Resistance Measurement Resolution:
10mΩ
Safety Category Level:
CAT III, CAT IV
Capacitance Measurement Resolution:
1pF
Best DC Voltage Accuracy:
0.05 %
Best Temperature Measurement Accuracy:
+0.1 %
Dimensions:
196 x 90 x 47.1mm
Minimum Operating Temperature:
0°C
Height:
47.1mm
Weight:
570g
Best DC Current Accuracy:
0.8 %
Safety Category Voltage:
300 V, 600 V, 1000V
Battery Type:
AA, NiMH
Maximum Operating Temperature:
+40°C
Best Resistance Measurement Accuracy:
0.2 %
Best AC Voltage Accuracy:
0.5 %
Length:
196mm
Best AC Current Accuracy:
0.8 %
Width:
90mm
