Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
CA 5233
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature
Calibrated:
UKAS
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum Capacitance Measurement:
1mF
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+760°C
Maximum Frequency:
1kHz
AC Current Measurement Resolution:
0.001A ac
DC Current Measurement Resolution:
0.001A dc
AC Voltage Measurement Resolution:
0.01mV ac
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
0.01mV dc
Capacitance Measurement Resolution:
10pF
Temperature Measurement Resolution:
1°C
Safety Category Level:
CAT III, CAT IV
Length:
155mm
Width:
75mm
Weight:
320g
Dimensions:
155 x 75 x 75mm
Battery Type:
9V
Safety Category Voltage:
600V
Height:
75mm
