Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
CA 703
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Diode, NCV Non contact voltage, Resistance
Absolute Maximum DC Current Measurement:
200mA dc
Absolute Maximum AC Current Measurement:
200mA ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
20MΩ
True RMS:
No
Maximum Frequency:
400Hz
Safety Category Level:
CAT IV
Best Resistance Measurement Accuracy:
±0.8 % + 5 digits
Battery Type:
AAA 1.5 V, IEC LR03
Safety Category Voltage:
CAT III 1000 V, CAT IV 600V
Best DC Current Accuracy:
±2 % + 8 digits
Weight:
2.6Ah
Height:
104mm
Minimum Operating Temperature:
0°C
Best AC Voltage Accuracy:
±1 % + 8 digits
Maximum Operating Temperature:
+40°C
Dimensions:
104 x 55 x 32.5mm
Best DC Voltage Accuracy:
±0.5 % + 3 digits
Length:
32.5mm
Best AC Current Accuracy:
±1 % + 8 Digits
Width:
55mm
