Multimeter Type:
Handheld
Display Type:
Digital
Model Number p:
CA 5233
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, NCV Non contact voltage, Resistance, Temperature
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum DC Current Measurement:
10A dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum AC Current Measurement:
10A ac
Absolute Maximum Resistance Measurement:
60MΩ
Absolute Maximum Capacitance Measurement:
1mF
True RMS:
Yes
Absolute Maximum Temperature Measurement:
+760°C
Maximum Frequency:
3kHz
AC Current Measurement Resolution:
0.001A ac
DC Current Measurement Resolution:
0.001A dc
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
0.01mV dc
AC Voltage Measurement Resolution:
0.01mV ac
Safety Category Level:
CAT III, CAT IV
Temperature Measurement Resolution:
0.1°C
Capacitance Measurement Resolution:
0.01nF
Best Resistance Measurement Accuracy:
±0.3 % + 4 digits
Minimum Operating Temperature:
0°C
Height:
155mm
Weight:
320g
Best DC Current Accuracy:
±1.5 % + 3 digits
Best AC Current Accuracy:
±2 % + 3 Digits
Width:
75mm
Safety Category Voltage:
CAT III 600V, CAT IV 600V
Best AC Voltage Accuracy:
±2 % + 3 digits
Best Capacitance Measurement Accuracy:
±3.5 % + 4 digits
Dimensions:
155 x 75 x 55mm
Best Temperature Measurement Accuracy:
±2 % + 5 °C
Battery Type:
9 V, IEC 6LR61
Maximum Operating Temperature:
+50°C
Length:
55mm
Best DC Voltage Accuracy:
±0.2 % + 2 digits
