Product Type:
MOSFET
Channel Type:
Type N
Maximum Continuous Drain Current Id:
360mA
Maximum Drain Source Voltage Vds:
50V
Package Type:
SC-88
Mount Type:
Surface
Pin Count:
6
Maximum Drain Source Resistance Rds:
4.5Ω
Channel Mode:
Enhancement
Typical Gate Charge Qg @ Vgs:
0.6nC
Forward Voltage Vf:
0.8V
Minimum Operating Temperature:
150°C
Maximum Power Dissipation Pd:
310mW
Maximum Gate Source Voltage Vgs:
20 V
Maximum Operating Temperature:
-55°C
Transistor Configuration:
Single
Length:
2.2mm
Standards/Approvals:
J-STD-020, UL 94V-0, AEC-Q101, MIL-STD-202, RoHS
Width:
1.35 mm
Height:
1mm
Number of Elements per Chip:
1
Automotive Standard:
AEC-Q200, AEC-Q101, AEC-Q100
