Power Rating:
2.2 kW
Phase:
1
Supply Voltage:
230 V ac
Current Rating:
10.5 A
For Use With:
Conveyor Belt Systems, Fan Application, Pump, Three Phase Motors
Field Bus Communication Type:
CANOpen
IP Rating:
IP20
Output Frequency:
0 → 50Hz
STO:
No
Drive Type:
Vector Control
Mounting Type:
Flange Mount
Filter Included:
Yes
Better World Claim:
Saves energy
Better World Product:
Yes
Overall Width:
152mm
Standards Met:
CE, cUL, EAC, RCM, UkrSEPRO, UL
Overall Depth:
231mm
Function:
Motor Control
Overall Length:
107mm
Special Features:
Control of High Efficient IE4 Motors, DC Braking, Detachable Control Signal Terminal Strip, Fast Commissioning with 14 Basic Parameters, Full Short Circuit Protection, Integrated Braking Transistor, Integrated Canopen & Modbus RTU, Integrated EMC Filter, Integrated PI Controller, Large Overload Capability, Sensorless Vector Control, V/F Control, Voltage Boost
