1778081 Phoenix Contact
1778081 Phoenix Contact
1778081 Phoenix Contact
1778081 Phoenix Contact

TERM BLOCK PLUG 4POS STR 7.62MM

Phoenix Contact 1778081

Manufacturer:
Phoenix Contact
Manufacturer Part No:
1778081
Enrgtech Part No:
ET11726196
Warranty:
Manufacturer
SAR 120.86
Checking for live stock
Current Rating:
41A
Voltage Rating:
1 kV
Series:
PC 5/4-STCL1-7.62
Colour:
Green
Material:
Polyamide, Tin
Pluggable Terminal Block Type:
Plug
Termination Method:
Screw
Pitch:
7.62mm
Number of Contacts:
4
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M3
Wire Strip Length:
10mm
Type:
Plug, Female Sockets
Number of Positions:
4
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.2-10mm²
Plug Wire Entry:
180°
Insulation Height:
0.776" (19.70mm)
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
41A
Number of Levels:
1
Wire Gauge or Range - AWG:
8-24 AWG
Voltage - UL:
600 V
Torque - Screw:
0.5-0.8 Nm (4.4-7.1 Lb-In)
standardLeadTime:
10 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
1 kV
Ingress Protection:
-
Features:
Latch Lock
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON PC
Positions Per Level:
4
Packaging:
Bulk
Header Orientation:
-
Current - UL:
41 A
Pitch:
0.300" (7.62mm)
Contact Material:
-
ECCN:
EAR99
pdf icon
Datasheet(Technical Reference)
pdf icon
1778081(Datasheets)
