1776155 Phoenix Contact
1776155 Phoenix Contact
1776155 Phoenix Contact
1776155 Phoenix Contact

TERM BLOCK PLUG 4POS STR 5.08MM

Phoenix Contact 1776155

Manufacturer:
Phoenix Contact
Manufacturer Part No:
1776155
Enrgtech Part No:
ET11619402
Warranty:
Manufacturer
SAR 107.53
Checking for live stock
Current Rating:
12A
Mounting Type:
Plug-In
Voltage Rating:
320 V
Series:
COMBICON MSTB
Body Orientation:
Straight
Termination Method:
Screw
Number of Rows:
1
Pitch:
5.08mm
Number of Contacts:
4
Type:
Plug
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M3
Wire Strip Length:
7mm
Type:
Plug, Female Sockets
Number of Positions:
4
Contact Tail Length:
-
Wire Gauge or Range - mm²:
0.2-2.5mm²
Plug Wire Entry:
180°
Insulation Height:
-
REACH Status:
REACH Unaffected
Material Flammability Rating:
UL94 V-0
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-30 AWG
Voltage - UL:
300 V
Torque - Screw:
0.5-0.6 Nm (4.4-5.3 Lb-In)
standardLeadTime:
12 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
630 V
Ingress Protection:
-
Features:
Retention Latches (Non-Wire Side), Strain Relief
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON MSTB
Positions Per Level:
4
Packaging:
Bulk
Header Orientation:
-
Current - UL:
10 A
Pitch:
0.200" (5.08mm)
Contact Material:
-
ECCN:
EAR99
pdf icon
Printed-circuit board connector - MSTB 2,5/ 4-STZ-5,08 - 1776155(Technical Reference)
pdf icon
1776155(Datasheets)
pdf icon
Design of the material displacement chg 18/JUL/2022(PCN Design/Specification)
pdf icon
Multiple Devices Approval Markings 19/Nov/2018(PCN Design/Specification)
