1853036 Phoenix Contact
1853036 Phoenix Contact
1853036 Phoenix Contact
1853036 Phoenix Contact

TERM BLOCK PLUG 4POS STR 5.08MM

Phoenix Contact 1853036

Manufacturer:
Phoenix Contact
Manufacturer Part No:
1853036
Enrgtech Part No:
ET11372600
Warranty:
Manufacturer
SAR 110.93
Checking for live stock
Current Rating:
12A
Voltage Rating:
630 V
Series:
TMSTBP 2.5/ 4-ST-5.08
Colour:
Green
Material:
Polyamide, Tin (Contact)
Pluggable Terminal Block Type:
Plug
Termination Method:
Screw
Pitch:
5.08mm
Number of Contacts:
4
HTSUS:
8536.90.4000
RoHS Status:
ROHS3 Compliant
Termination Style:
Screw - Rising Cage Clamp
Housing Material:
Polyamide (PA), Nylon
Operating Temperature:
-
Screw Size:
M3
Wire Strip Length:
7mm
Type:
Plug, Female Sockets
Number of Positions:
4
Wire Gauge or Range - mm²:
0.2-2.5mm²
Plug Wire Entry:
180°
Insulation Height:
1.138" (28.90mm)
REACH Status:
REACH Unaffected
edacadModel:
1853036 Models
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/550599
Package:
Bulk
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
12A
Contact Tail Length:
-
Voltage - UL:
300 V
Torque - Screw:
0.5-0.6 Nm (4.4-5.3 Lb-In)
standardLeadTime:
7 Weeks
Contact Mating Finish:
Tin
Voltage - IEC:
630 V
Ingress Protection:
-
Features:
Retention Latches (Non-Wire Side)
Mounting Type:
Free Hanging (In-Line)
Color:
Green
Series:
COMBICON TMSTBP
Positions Per Level:
4 (Mate), 8 (Input)
Header Orientation:
-
Current - UL:
15 A
Wire Gauge or Range - AWG:
12-30 AWG
Pitch:
0.200" (5.08mm)
Number of Levels:
1 (Mate), 2 (Input)
Contact Material:
-
ECCN:
EAR99
pdf icon
Datasheet 1853036(Technical Reference)
pdf icon
1853036(Datasheets)
