Coil Voltage:
12V dc
Contact Configuration:
SPDT
Mounting Type:
DIN Rail
Series:
1RM
Number of Poles:
1
Load Current Rating:
12A
Maximum Input Voltage:
250V ac
Switching Voltage:
12 V dc → 250V ac
Terminal Type:
Screw
Depth:
15.8mm
Height:
65mm
Length:
76mm
Contact Material:
Silver Alloy
Input Current:
16A
Turn Off Time:
8ms
Special Features:
Change Over Contacts, Supplied Complete, Relay, LED, Socket, Ejector Clip and Identification Label, 1Part Number for Simple Ordering AC & DC Coils, Supply Status LED as Standard 35mm Din Rail Mounting, 2 Socket Types For Ease of Installation, 12A and 16A Versions
Standards Met:
CE, cURus
Minimum Operating Temperature:
-40°C
Operating Temperature Range:
-40 → +85°C
Dimensions:
76 x 15.8 x 65mm
Relay Switching Classification:
Interface Relay Module
Turn On Time:
15ms
Maximum Operating Temperature:
+85°C
Life:
100000 (AC, Mechanical), 100000 (DC, Electrical), 10000000 (DC, Mechanical), 50000 (AC, Electrical)
Control Resistance:
100mΩ
