Series:
C
Type:
Switched Mode
Electrical Phase:
1
Number of Outputs:
1
Input Voltage:
230V ac
AC or DC Output Voltage:
dc
Output Voltage:
24V dc
Output Current:
5A
Dimensions:
32 x 124 x 117mm
Height:
124mm
Depth:
117mm
Width:
117mm
Special Features:
Fuse Breaking
Minimum Temperature:
-10°C
Mounting Type:
DIN Rail Mount
Load Regulation:
100mV
Standards Met:
ABS, CB Scheme, cCSAus, CE Certified, CISPR 11, CISPR 22 Class B, cULus Listed, cULus Recognised, EAC, EN 50178, EN 55011, EN 55022, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-3, EN 61000-6-4, EN/IEC 60529, FCC Part 15, GL, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-6, IEC 60364-4-41, IEC 62103, IEC/CISPR 16-1-2, IEC/CISPR 16-2-1, IEC/EN 60204-1, IEC/EN 60950-1, MIL HDBK 217F, VDE 0160
MTBF:
144000h
Output Voltage Adjustment Range:
24 → 28V
Ripple And Noise:
<50mV Pk-Pk
Maximum Temperature:
+70°C
