Number of Input Channels:
4
Model Number:
1736
Measurement Parameters:
Current, Current Harmonic, Frequency, TDD, THD Current, THD Voltage, Unbalance, Voltage, Voltage Harmonic
Interface Type:
Bluetooth, USB, Wi-Fi
Data Logger Type:
Three Phase Power
Maximum Voltage Measurement:
1000V
Communication Protocol:
USB
Minimum Temperature Measurement:
-10°C
Maximum Temperature Measurement:
+50 °C
Power Source:
Battery
IP Rating:
IP50
Minimum Operating Temperature:
-10°C
Maximum Operating Temperature:
+50°C
Maximum Current Measurement:
6000A
Display Type:
LCD
Best Voltage Measurement Accuracy:
± 0.2 %
Dimensions:
198 x 167 x 55mm
Model Number p:
1736
Battery Type:
Rechargeable Lithium-Ion
Current Measurement Resolution:
± 1 %
Battery Life:
4 Hours
Cleanroom:
95%RH
Best Current Measurement Accuracy:
± 1 %
