09661116502 Harting D-Sub 9 Way Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC Nut

Harting 9 way Solder D-Sub Miniature Sockets Straight - 2.74 mm Pitch From Harting, a range of 9 way solder D-sub miniature connectors with straight stamped female contacts. The DIN 41652 sockets have copper alloy contacts housed in a robust metal shell. Secured in the panel with a fixing flange and 4 to 40 UNC thread. The D-sub miniature connectors in this series have performance level 2 and 3. Features and Benefits • Robust metal shell
• 6.5A rated current
• Wave soldering termination
• Performance level 2 and 3
• Stamped contacts

For more information please check the datasheets.

HARTING 09661116502 Harting D-Sub 9 Way Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC Nut

Name: Harting D-Sub 9 Way Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC Nut
Brand: HARTING
SKU: ET11406596
Availability: InStock

Manufacturer:

HARTING

Manufacturer Part No:

09661116502

Enrgtech Part No:

ET11406596

Warranty:

Manufacturer

SAR 40.17

Checking for live stock

Number of Contacts:

Gender:

Female

Body Orientation:

Straight

Mounting Type:

Through Hole

Pitch:

2.74 mm, 2.84mm

D Connector Type:

Standard D-Sub

Mounting Hardware:

4-40 UNC Nut

Termination Method:

Solder

Mixed Contact Layout:

9W2

Current Rating:

6.5A

Housing Material:

Glass Fibre Reinforced Thermoplastic

Length:

31.2mm

Female 9 way D-sub connector drawing-7f169140(datasheets)
