Absolute Maximum AC Current Measurement:
1500A ac
Absolute Maximum DC Current Measurement:
2000A dc
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
66MΩ
Model Number:
MARCM87
AC Current Measurement Resolution:
100mA
DC Current Measurement Resolution:
100mA
Best DC Current Accuracy:
±(2% rdg + 5dgts)
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
±(2% rdg + 10dgts)
Best AC Voltage Accuracy:
±(1.5% rdg + 8dgts)
Functions Measured:
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature
True RMS:
Yes
Best DC Voltage Accuracy:
±(0.5% rdg + 2dgts)
Jaw Capacity Busbars:
57mm
Safety Category Level:
CAT II, CAT III, CAT IV
AC Voltage Measurement Resolution:
1mV
Safety Category Voltage:
1000 (CAT II & CAT III) V, 600 (CAT IV) V
Battery Type:
9V
Weight:
585g
Battery Life:
75 h
Temperature Measurement Resolution:
1°C
Maximum Conductor Size:
57mm
Resistance Measurement Resolution:
100mΩ
Length:
108mm
Height:
281mm
DC Voltage Measurement Resolution:
1mV
Dimensions:
108 x 53 x 281mm
Minimum Operating Temperature:
0°C
Absolute Maximum Temperature Measurement:
+1000°C
Maximum Operating Temperature:
+40°C
Display Type:
Bar Graphs, LCD
Best Resistance Measurement Accuracy:
±1.0% + 5 Digits
Safety Category:
CAT II 1000 V; 10 A, CAT III 1000 V; 10 A, CAT IV 600V
Best Temperature Measurement Accuracy:
±1.0% + 2 Digits
Power Source:
Battery
Width:
53mm
