Absolute Maximum AC Current Measurement:
1000A ac
Absolute Maximum DC Current Measurement:
1000A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
100kΩ
Model Number:
158B
Moulded/Fold Flat:
Bluetooth
Calibrated:
RSCAL
Best DC Current Accuracy:
±(1.5% rdg + 5dgts)
Clamp Meter Type:
Power Clamp Meter
Best AC Current Accuracy:
±(1.5% rdg + 5dgts)
Best AC Voltage Accuracy:
±(1% rdg + 5dgts)
Functions Measured:
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Harmonics, Power, Power Factor, Resistance, Temperature, THD
True RMS:
Yes
Jaw Capacity Busbars:
33mm
Best DC Voltage Accuracy:
±(0.7% rdg + 2dgts)
Power Source:
Battery
Non-Contact Voltage Detector:
Yes
Width:
103mm
Length:
258mm
Resistance Measurement Resolution:
100mΩ
Dimensions:
258 x 103 x 55mm
Temperature Measurement Resolution:
0.1°C
Safety Category Voltage:
600 V, 1000V
Battery Type:
1.5 V AAA, Alkaline
Absolute Maximum Temperature Measurement:
+1000°C
Safety Category:
CAT III 1000 V, CAT IV 600V
Best Resistance Measurement Accuracy:
±1 + 5 Digit %
Display Type:
Bar Graphs, LED
Maximum Operating Temperature:
+50°C
Safety Category Level:
CAT III, CAT IV
Best Temperature Measurement Accuracy:
±1 + 3 °C %
Minimum Operating Temperature:
0°C
Height:
55mm
Maximum Conductor Size:
40 Dia.mm
Battery Life:
50 h
Weight:
600g
