Absolute Maximum AC Current Measurement:
200A ac
Absolute Maximum AC Voltage Measurement:
750V ac
Absolute Maximum Resistance Measurement:
2000Ω
Model Number:
ICMA5
Calibrated:
RSCAL
Clamp Meter Type:
AC Open Jaw Clamp Meter
Best AC Current Accuracy:
±3% +3 digits
Best AC Voltage Accuracy:
±1.5% + 3 Digits
Jaw Capacity Busbars:
16mm
Best DC Voltage Accuracy:
±1% + 2 Digits
Functions Measured:
AC Current, AC Voltage, Continuity, DC Voltage, Diode Test, Resistance
Dimensions:
66 x 46 x 198mm
Battery Type:
9V, IEC 6F22, NEDA 1604
Safety Category Voltage:
600 V, 1000V
Safety Category Level:
CAT III, CAT IV
Weight:
280g
Battery Life:
250 h
Maximum Conductor Size:
16 (Dia.)mm
Width:
46mm
Height:
198mm
Minimum Operating Temperature:
-20°C
Power Source:
Battery
Maximum Operating Temperature:
+50°C
Length:
66mm
Best Resistance Measurement Accuracy:
±1% + 2 Digits
Safety Category:
CAT III 1000 V, CAT IV 600V
