Absolute Maximum AC Current Measurement:
2100A ac
Absolute Maximum DC Current Measurement:
2500A dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
40MΩ
Model Number:
ICM2000N
AC Current Measurement Resolution:
100mA
DC Current Measurement Resolution:
100mA
Best DC Current Accuracy:
±(1.5% rdg + 3dgts)
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
±(1.5% rdg + 5dgts)
Best AC Voltage Accuracy:
±(1.5% rdg + 5dgts)
Jaw Capacity Busbars:
55mm
True RMS:
Yes
Best DC Voltage Accuracy:
±(1.5% rdg + 3dgts)
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Frequency, Resistance
Safety Category Voltage:
600V
Safety Category Level:
CAT III
Weight:
647g
Maximum Operating Temperature:
+40°C
Display Type:
LCD
Best Resistance Measurement Accuracy:
±1.5 % ± 3 Digits
Safety Category:
CAT III 600 V
Battery Type:
9V, IEC 6F22, NEDA 1604
Resistance Measurement Resolution:
100mΩ
Length:
112mm
Width:
46mm
Power Source:
Battery
Maximum Conductor Size:
55mm
AC Voltage Measurement Resolution:
100µV
Height:
271mm
Minimum Operating Temperature:
0°C
DC Voltage Measurement Resolution:
100µV
Dimensions:
112 x 46 x 271mm
