Absolute Maximum AC Current Measurement:
60A ac
Absolute Maximum AC Voltage Measurement:
400V ac
Absolute Maximum Resistance Measurement:
400Ω
Model Number:
ILCM03A
AC Current Measurement Resolution:
10µA
Clamp Meter Type:
Leakage Clamp Meter
Best AC Current Accuracy:
±(1% rdg + 3dgts)
Best AC Voltage Accuracy:
±(1.5% rdg + 2dgts)
Jaw Capacity Busbars:
30mm
Functions Measured:
AC Current, AC Voltage, Resistance
Weight:
200g
Display Type:
LCD
Maximum Conductor Size:
30mm
DC Voltage Measurement Resolution:
100mV
Dimensions:
62 x 35.6 x 210mm
Battery Type:
1.5 V
Resistance Measurement Resolution:
100mΩ
Power Source:
Battery
Minimum Operating Temperature:
-10°C
Height:
210mm
Width:
35.6mm
AC Voltage Measurement Resolution:
100mV
Length:
62mm
Best Resistance Measurement Accuracy:
±1 % ± 2 Digits
Maximum Operating Temperature:
+50°C
