Absolute Maximum AC Current Measurement:
400A ac
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
20MΩ
Model Number:
RS380
AC Current Measurement Resolution:
10mA
Clamp Meter Type:
AC Current Clamp Meter
Best AC Current Accuracy:
±(2.5% rdg + 5dgts)
Best AC Voltage Accuracy:
±(1.5% rdg + 8dgts)
True RMS:
Yes
Jaw Capacity Busbars:
23mm
Best DC Voltage Accuracy:
±(1.5% rdg + 2dgts)
Functions Measured:
AC Current, AC Voltage, Continuity, DC Voltage, Diode Test, Resistance, Temperature
DC Voltage Measurement Resolution:
100µV
Non-Contact Voltage Detector:
Yes
Width:
40mm
Length:
82mm
Resistance Measurement Resolution:
100mΩ
Dimensions:
82 x 40 x 230mm
Power Source:
Battery
Safety Category Level:
CAT III
Safety Category:
CAT III 600 V
Temperature Measurement Resolution:
1 °C, 1 °F
Safety Category Voltage:
600V
Battery Type:
AAA
Absolute Maximum Temperature Measurement:
+1400 °F, +760°C
Best Resistance Measurement Accuracy:
±1% ± 4 Digits
Weight:
230g
AC Voltage Measurement Resolution:
100µV
Height:
230mm
Minimum Operating Temperature:
+5°C
Display Type:
LCD
Maximum Operating Temperature:
+40°C
Best Temperature Measurement Accuracy:
±3% ± 5 Digits
