Absolute Maximum AC Current Measurement:
2000A ac
Absolute Maximum DC Current Measurement:
2000A dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
400kΩ
Model Number:
355
AC Current Measurement Resolution:
10mA
DC Current Measurement Resolution:
10mA
Best DC Current Accuracy:
±(1.5% rdg +5 Digits)
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
±(1.5% rdg +5 Digits)
Best AC Voltage Accuracy:
±(1% rdg +5 Digits)
True RMS:
Yes
Functions Measured:
AC Current, AC Voltage, Continuity, DC Current, DC Voltage, Frequency, Resistance
Jaw Capacity Busbars:
58mm
Best DC Voltage Accuracy:
±(1% rdg +5 Digits)
Maximum Operating Temperature:
+50°C
Maximum Conductor Size:
58mm
AC Voltage Measurement Range:
4 V, 40 V, 400 V, 600 V
Power Source:
Battery
Length:
300mm
Resistance Measurement Resolution:
100mΩ
DC Voltage Measurement Resolution:
1mV
Safety Category Voltage:
600 V, 1000V
Battery Type:
AA
Display Type:
LCD
Best Resistance Measurement Accuracy:
±1.5% +5 Digits
Safety Category:
CAT III 1000 V, CAT IV 600V
Minimum Operating Temperature:
0°C
AC Voltage Measurement Resolution:
1mV
Height:
52mm
Dimensions:
300 x 98 x 52mm
Glove Type:
40/400/2000/1400 A
Width:
98mm
Safety Category Level:
CAT IV, CAT III
Weight:
814g
Battery Life:
100 h
AC Current Measurement Range:
40A, 400A, 2000A, 1400 A
