Absolute Maximum AC Current Measurement:
2000A ac
Absolute Maximum DC Current Measurement:
3000A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
99.99kΩ
Moulded/Fold Flat:
Bluetooth
Model Number:
F607
AC Current Measurement Resolution:
10mA
DC Current Measurement Resolution:
10mA
Best DC Current Accuracy:
±(1% rdg + 3dgts)
Clamp Meter Type:
Power/Harmonics Clamp Meter
Best AC Current Accuracy:
±(1% rdg + 3dgts)
Best AC Voltage Accuracy:
±(1% rdg + 3dgts)
Best DC Voltage Accuracy:
±(1% rdg + 3dgts)
True RMS:
Yes
Jaw Capacity Busbars:
60mm
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Diode, Frequency, Harmonics, In-Rush Current, Power, Power Factor, Resistance
Battery Life:
350 h
DC Voltage Measurement Resolution:
10mV
Maximum Conductor Size:
60mm
AC Voltage Measurement Resolution:
10mV
Height:
41mm
Minimum Operating Temperature:
-20°C
Best Resistance Measurement Accuracy:
±1 % + 5 digits
Safety Category:
CAT III 1000 V, CAT IV 1000V
Battery Type:
LR6
Safety Category Voltage:
1000V
Dimensions:
111 x 41 x 296mm
Resistance Measurement Resolution:
100mΩ
Length:
296mm
Width:
111mm
Power Source:
Battery
Weight:
640g
Safety Category Level:
CAT III, CAT IV
Maximum Operating Temperature:
+55°C
Display Type:
Backlit LCD
