Absolute Maximum AC Current Measurement:
1000A ac
Absolute Maximum DC Current Measurement:
1500A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
99.99kΩ
Moulded/Fold Flat:
Bluetooth
Model Number:
F407
AC Current Measurement Resolution:
10mA
DC Current Measurement Resolution:
10mA
Best DC Current Accuracy:
±(1% rdg + 3dgts)
Clamp Meter Type:
Power/Harmonics Clamp Meter
Best AC Current Accuracy:
±(1% rdg + 3dgts)
Best AC Voltage Accuracy:
±(1% rdg + 3dgts)
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Diode, Frequency, Harmonics, In-Rush Current, Power, Power Factor, Resistance
Best DC Voltage Accuracy:
±(1% rdg + 3dgts)
Jaw Capacity Busbars:
48mm
True RMS:
Yes
Power Source:
Battery
Width:
92mm
Length:
272mm
Resistance Measurement Resolution:
100mΩ
Dimensions:
92 x 41 x 272mm
DC Voltage Measurement Resolution:
10mV
Minimum Operating Temperature:
-20°C
Height:
41mm
Safety Category Voltage:
1000V
Battery Type:
AA
Safety Category:
CAT III 1000V
Best Resistance Measurement Accuracy:
±1 % + 5 digits
Display Type:
Backlit LCD
Maximum Operating Temperature:
+55°C
AC Voltage Measurement Resolution:
10mV
Maximum Conductor Size:
48mm
Battery Life:
350 h
Weight:
600g
Safety Category Level:
CAT III, CAT IV
