Absolute Maximum AC Current Measurement:
200A ac
Absolute Maximum DC Current Measurement:
200A dc
Absolute Maximum AC Voltage Measurement:
1000V ac
Absolute Maximum DC Voltage Measurement:
1000V dc
Absolute Maximum Resistance Measurement:
60MΩ
Model Number:
VT8
Calibrated:
RSCAL
AC Current Measurement Resolution:
100mA
DC Current Measurement Resolution:
100mA
Best DC Current Accuracy:
±2.5 %
Clamp Meter Type:
AC-DC Open Jaw Clamp Meter
Best AC Current Accuracy:
±2.5 %
Best AC Voltage Accuracy:
±1.5 %
True RMS:
Yes
Functions Measured:
AC Current
Jaw Capacity Busbars:
15.5mm
Best DC Voltage Accuracy:
±1.5 %
Dimensions:
210 x 35 x 53mm
DC Voltage Measurement Resolution:
100mV
Safety Category Level:
CAT III, CAT IV
Safety Category:
CAT III 1000 V, CAT IV 600V
Weight:
163.7g
Length:
210mm
Display Type:
LCD
Safety Category Voltage:
600 V, 1000V
Battery Type:
AA
Maximum Operating Temperature:
+50°C
Best Resistance Measurement Accuracy:
±1.5 %
Width:
35mm
Non-Contact Voltage Detector:
Yes
Power Source:
Battery
AC Voltage Measurement Resolution:
100mV
Minimum Operating Temperature:
-10°C
Height:
53mm
