Eaton , SPST 4 Position 45° Multi Step Cam Switch, 690V ac, 20A, Toggle Actuator

Manufacturer:

Manufacturer Part No:

050716 T0-2-8241/E

Enrgtech Part No:

ET22733900

Warranty:

Manufacturer

SAR 27.22

Checking for live stock

Pole and Throw Configuration:

SPST

Cam Switch Type:

Multi Step Cam Switch

Normal State Configuration:

Electrical Phase:

1, 3

Maximum Current:

20A

Maximum Voltage:

690V ac

Number of Positions:

Terminal Type:

Screw

Angle of Throw:

45°

Actuator Type:

Toggle

Mounting Type:

Flush Mount

Dimensions:

48 x 90 x 48mm

0900766b814d59eb.pdf(datasheets)

A700000009709477.pdf(datasheets)

A700000009711460.pdf(datasheets)
